UNRIVALLED HIGH RESOLUTION | 400×300 phase pixels
- Ultra high resolution – 400×300 measurement points – for robust wavefront analysis
- Achromaticity from 400 to 1100nm – without calibrating
- Compact
- Self-referenced: insensitive to vibrations & easy to align
- Easy set-up: direct measurement of diverging and collimated beam
- Achieves easy and accurate quantitative phase imaging
Specifications
| Wavelength range | 400 - 1100 nm |
| Aperture dimension | 8.9 x 11.8mm2 |
| Spatial resolution | 29.6 µm |
| Phase & intensity sampling | 300 x 400 (> 120 000 points) |
| Resolution (Phase) | < 2 nm RMS |
| Accuracy | 15 nm RMS |
| Acquisition rate | > 10 fps |
| Real-time processing frequency | > 3 fps (full resolution) |
| Computer connection | Giga Ethernet |
| Dimensions (w x h x l) | 54 x 46 x 79 mm |
| Weight | ~250 g |
